aluron AS 80US
AS 80US
WINDOW SYSTEM WITH HIDDEN SASH
The AS 80US (hidden sash) system is designed for single and multi-casement windows in which the desired aesthetic effect is to achieve a view of an invisible window sash from the outside of the building. All adjacent fixed and opening windows make the view of all sections the same. The AS 80US system is compatible with all Aluron aluminum systems.
■Thermal isolation
■Tightness
■Glazing
■Resistance
■Waterproof
Optional equipment
Uw ≥ 0,71 W/m²K
■Tightness
Class 4
■Glazing
min. thickness 21 mm
max. thickness 68 mm
■Resistance
Class C3
■Waterproof
Class E 1950
Optional equipment
Product features
- Window frame depth of 80 mm
- Glazing range up to 68 mm
- Window sash depth of 84 mm
- 3-chamber construction
- Thermal insulation Uw window from 0.71 W/m²K
- Air permeability class 4
- Wind load resistance class C3
